Toolless Maintenance Classic LED Batten Fixture
  • Toolless Maintenance Classic LED Batten FixtureToolless Maintenance Classic LED Batten Fixture
  • Toolless Maintenance Classic LED Batten FixtureToolless Maintenance Classic LED Batten Fixture
  • Toolless Maintenance Classic LED Batten FixtureToolless Maintenance Classic LED Batten Fixture
  • Toolless Maintenance Classic LED Batten FixtureToolless Maintenance Classic LED Batten Fixture
  • Toolless Maintenance Classic LED Batten FixtureToolless Maintenance Classic LED Batten Fixture

Toolless Maintenance Classic LED Batten Fixture

Fanxstar proudly holds a prominent position as a leading Toolless Maintenance Classic LED Batten Fixture manufacturer and supplier of state-of-the-art LED batten lights in China. Among our stellar offerings, the Batman B2 stands out—a seamless splice High output batten symbolizing our dedication to excellence.
Over the past 7 years, our hallmark has been unwavering: delivering clients exceptional LED batten luminaires renowned for their top-notch quality and competitive pricing. Our global presence spans across 90 countries and regions through our robust export network. Our commitment persists: actively collaborating with partners and clients, perpetually innovating to craft more adaptable, personalized, and user-centric LED batten light. This unyielding commitment shapes a mutually advantageous business model, ensuring success and satisfaction for all involved.

Send Inquiry

Product Description

Toolless Maintenance Classic LED Batten Fixture

FANXSTAR Classic LED Batten Fixture Toolless Removable Maintenance
IP20 Multi-Purpose Modular Diffused LED Battens Batman B2

FANXSTAR designed the LED batten light Batman B2 Toolless Maintenance Classic LED Batten Fixture range of Classic LDE Fixture Battens replaces 4ft to 6ft, T5 and T8 batten fittings with Tri-3CCT of 3000K, 4000K or 5700K. They have end and rear cable entry and their flat end profile allows for end-to-end lighting designs.

TYPICALLY REPLACES

1/2 x 35W T5 fluorescent.

1/2 x 58W T8 fluorescent.

1/2 x 70W T8 fluorescent.

Compared to similar products on the market, the LED batten fixtures Batman B2 uses an aluminum heatsink to improve heat dissipation and CRCA steel sheet with white powder coating, which has the advantages of lower light decay and longer service life. Inspired by Fanxstar's engineering practice, when multiple lamps are used together, especially in supermarket or shopping mall, the single LED batten light Batman B2 can be easily maintained without adjusting the main line, because the modular batten body withed driver is allowed to drop for fast and toolless re-assembly. LED batten luminaire comes with 5-year warranty.


General, Dual-way/3CCT and Emergency Specification data for FANXSTAR LED Batten light

LED Batten Specifications data with 1200mm length

Version Item No. Description MM=Color temp. Luminous flux
Std. B2-4FT40-MMK-N 4' Diffused LED Batten light ,
Voltage200-240V 50/60Hz,
Power 40W, 80CRI, 20-65K
LED Qty 266pcs
2700K
4000K
5000K
5700K
6500K
4090 lm
4360 lm
4400 lm
4360 lm
4268 lm
3CCT B2-4FT40-MMK-X 4' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 40W, 80CRI, 20-65K
3000K/4000K/5000K Switchable
Dual-way 4000K Options available
3000K
4000K
5000K
102m/w
115lm/w
110lm/w
EMG B2-4FT40-MMK-E 4' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 40W, 80CRI, 20-65K
Emergency 2W3HRS LiFePO4
AS/NZS 2293.3 compliant
2700K
4000K
5000K
5700K
6500K
4090 lm
4360 lm
4400 lm
4360 lm
4268 lm


LED Batten Specifications data with 1500mm length

Version Item No. Description MM=Color temp. Luminous flux
Std. B2-5FT60-MMK-N 5' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 60W, 80CRI, 20-65K
LED Qty 342pcs
2700K
4000K
5000K
5700K
6500K
6140 lm
6540 lm
6600 lm
6534 lm
6400 lm
3CCT B2-5FT60-MMK-X 5' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 60W, 80CRI, 20-65K
3000K/4000K/5000K Switchable
Dual-way 4000K Options available
3000K
4000K
5000K
102m/w
115lm/w
110lm/w
EMG B2-5FT60-MMK-E 5' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 60W, 80CRI, 20-65K
Emergency 2W3HRS LiFePO4
AS/NZS 2293.3 compliant
2700K
4000K
5000K
5700K
6500K
6140 lm
6540 lm
6600 lm
6534 lm
6400 lm


LED Batten Specifications data with 1800mm length

Version Item No. Description MM=Color temp. Luminous flux
Std. B2-6FT80-MMK-N 6' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 80W, 80CRI, 20-65K
LED Qty 464pcs
2700K
4000K
5000K
5700K
6500K
8190 lm
8712lm
8800 lm
8720 lm
8540 lm
3CCT B2-6FT80-MMK-X 6' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 80W, 80CRI, 20-65K
3000K/4000K/5000K Switchable
Dual-way 4000K Options available
3000K
4000K
5000K
102m/w
115lm/w
110lm/w
EMG B2-6FT80-MMK-E 6' Diffused LED Batten light,
Voltage200-240V 50/60Hz,
Power 80W, 80CRI, 20-65K
Emergency 2W3HRS LiFePO4
AS/NZS 2293.3 compliant
2700K
4000K
5000K
5700K
6500K
8190 lm
8712lm
8800 lm
8720 lm
8540 lm


FANXSTAR LED Batten lighting luminaire Batman B2 Toolless Maintenance Classic LED Batten Fixture Feature And Application

Both rear and end cable entry are available

Simple clip design and interlocking power cord for easy installation

Flat end allows for end-to-end light designs

1:1 replacement for 1/2-lamps T5/T8 fluorescent

Premium AL6063 body to improve heat dissipation

LVD Compliant with EN60598-2-22/62031/62778

Tri-CCT as 3000K, 4000K and 5700K available as options

2W3HRS LiFePO4 Emergency kits by emtrons technologies



FANXSTAR LED Batten light Batman B2 Toolless Maintenance Classic LED Batten Fixture Details

Both rear and end cable entry are available of LED Batten light

LED Fixture Batten 1:1 replacement for 2-lamps T5/T8 fluorescent

Premium AL6063 body to improve heat dissipation,LVD Compliant with EN60598-2-22/62031/62778 LED Batten lighting

Tri-CCT as 3000K, 4000K and 5700K available as options, 2W3HRS LiFePO4 Emergency kits by emtrons technologies of Emergency LED Batten lighting

The security wire for LED Batten light safe and easy installation


LED Batten Batman B2 Luminous Intensity Distribution Diagram


LED Batten Installation

Surface mounted and suspend mounted available
