Fanxstar is a company specializing in the production and supply of LED tri-proof lamps
in China. The Trilamp A9 unmatched combination of economic and performance LED weather- proof battens. In the last few years, we have been providing high quality LED tri-proof luminaires at competitive prices to customers in more than 90 countries and regions around the world. The Fanxstar team keeps in mind that we will actively cooperate with clients to continuously improve and explore more flexible, customized and user-friendly LED Tri proof lights in the further.
FANXSTAR TLA9 is a LED Tri proof luminaire,1:1 replace traditional lamps
with more affordable price, better quality and more energy saving. The LED tri proof light has been upgraded to IK10 & IP66 rate, flicker-free, ENEC, extra high efficiency output, EU=160lm/w. FANXSTAR LED Tri proof lamp TLA9 is working with an ENEC approved, flicker-free driver. More prominent, the power supply operates at ambient temperature Ta 60 , which make it can work at high environmental temperatures up to 55ºC. Lightning surge L-N: 2kV L/N-FG: 4kV (IEC61000-4-5) ,wihich make less prone to damage in harsh environments.These high performance parameters aqures higher-quality and longer-life for LED Tri proof luminaire TLA9.It is available in various sizes and wattages from 600mm to 1800mm.It has suspended, walled and surfaced mounted version. As well as the standard 1200mm and emergency 2W 3H versions with LiFePo4 battery, there are options with DALI,1-10V dimming , and integral microwave or batten mount PIR sensors. LED Tri proof luminaires comes with 5-year warranty
Weatherproof luminaires | Trilamp ECO
Type of Protection: IP66
Protection Class: Ⅰ
Impact Protection: IK10
Beam Angle: 120°
80CRI Standard And 90CRI Optional
Specifications using 5000K and subject to change. All parameters +/- 5%
LED Tri Proof luminaires Specifications data with 600mm length
Version | Item No. | Description | MM=Color temp. | Luminous flux | |
□ | ECO | TLA9-2FT20-MMK-N |
2' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 20W, 80CRI,20-65K LED Qty 64pcs |
2700K 4000K 5000K 5700K 6500K |
2260 lm 2420 lm 2460 lm 2440 lm 2380 lm |
□ | |||||
PRO | TLA9-2FT20-MMK-X |
2' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 20W, 80CRI,20-65K LED Qty 171pcs |
2700K 4000K 5000K 5700K 6500K |
2980 lm 3180 lm 3220 lm 3200 lm 3120 lm |
|
□ | |||||
Customized | TLA9-2FT20-MMK-1 |
2' LED Weatherproof Batten light, Voltage24-48V 50/60Hz, Power 20W, 80CRI,20-65K LED Qty 171pcs |
2700K 4000K 5000K 5700K 6500K |
2980 lm 3180 lm 3220 lm 3200 lm 3120 lm |
|
LED Tri Proof luminaires Specifications data with 1200mm length
Version | Item No. | Description | MM=Color temp. | Luminous flux | |
□ | ECO | TLA9-4FT40-MMK-N |
4' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 40W, 80CRI,20-65K LED Qty 102pcs |
2700K 4000K 5000K 5700K 6500K |
4520 lm 4840 lm 4920 lm 4880 lm 4760 lm |
□ | PRO | TLA9-4FT40-MMK-X |
4' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 40W, 80CRI,20-65K LED Qty 266pcs |
2700K 4000K 5000K 5700K 6500K |
5960 lm 6360 lm 6440 lm 6400 lm 6240 lm |
□ | |||||
Customized | TLA9-4FT40-MMK-1 |
4' LED Weatherproof Batten light, Voltage24-48V 50/60Hz, Power 40W, 80CRI,20-65K LED Qty 266pcs |
2700K 4000K 5000K 5700K 6500K |
5960 lm 6360 lm 6440 lm 6400 lm 6240 lm |
|
LED Tri Proof luminaires Specifications data with 1500mm length
Version | Item No. | Description | MM=Color temp. | Luminous flux | |
□ | ECO | TLA9-5FT60-MMK-N |
5' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 60W, 80CRI,20-65K LED Qty 153pcs |
2700K 4000K 5000K 5700K 6500K |
6780 lm 7260 lm 7380 lm 7320 lm 7140 lm |
□ | PRO | TLA9-5FT60-MMK-X |
5' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 60W, 80CRI,20-65K LED Qty 342pcs |
2700K 4000K 5000K 5700K 6500K |
8940 lm 9540 lm 9660 lm 9600 lm 9360 lm |
□ | Customized | TLA9-5FT60-MMK-1 |
5' LED Weatherproof Batten light, Voltage24-48V 50/60Hz, Power 60W, 80CRI,20-65K LED Qty 342pcs |
2700K 4000K 5000K 5700K 6500K |
8940 lm 9540 lm 9660 lm 9600 lm 9360 lm |
1:1 replacement for fluorescent lamps
Indirect light to illuminate the ceiling/wall mounting
High degree of protection IP66 & IK10
Flexible installation through sliding mounting bracket. Ideal for luminaire replacement
Φ1.5-2.5m² Through-wiring as standard for further luminaires
TRILAMP ECO Family is certified by CE/TUV/VDE/ENEC.
Suitable for use in moist/humid environments
Multi Lumen version: 2 steps adjustable luminous flux, 115LPW and 160LPW
(high lumen output equivalent to 2-lamp version; low lumen output equivalent to 1-lamp version)
Luminaires with limited surface temperature in accordance with DIN EN 60598-2-1
for use in environments in which a deposit of conductive dust on the luminaire can be expected
Operating range: -30°C to +50°C, operating range (with movement sensor): -20°C to +50°C
LED Tri proof Light with High degree of protection IP66 & IK10
Φ1.5-2.5m² Through-wiring as standard for further LED Tri proof luminaires
Flexible installation through sliding mounting bracket for LED Tri proof lighting. Ideal for luminaire replacement
LED Tri proof luminaire with Multi Lumen version: 2 steps adjustable luminous flux, 115LPW and 160LPW (high lumen output equivalent to 2-lamp version; low lumen output equivalent to 1-lamp version)
More details of LED Tri-proof luminaires
Item No. | Description | MM=Color temp. | Luminous flux | |
□ | TLA9-2FT20-MMK-S |
2' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 20W, 80CRI, 20-65K 5.8G Microwave Sensor, varies by customer |
2700K 4000K 5000K 5700K 6500K |
2200 lm 2340 lm 2360 lm 2340 lm 2300 lm |
□ | ||||
TLA9-4FT40-MMK-S |
4' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 40W, 80CRI, 20-65K 5.8G Microwave Sensor, varies by customer |
2700K 4000K 5000K 5700K 6500K |
4480 lm 4800 lm 4840 lm 4800 lm 4760 lm |
|
□ | ||||
TLA9-5FT60-MMK-S |
5' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 60W, 80CRI, 20-65K 5.8G Microwave Sensor, varies by customer |
2700K 4000K 5000K 5700K 6500K |
6780 lm 7200 lm 7320 lm 7260 lm 7200 lm |
|
LiFePO4 3.2V 3200mAH battery
Emergency POD for maximum in-service life and lowest maintenance cost
Emergency integral battery option also available
Up to D80 emergency classification
AS/NZS 2293.3 compliant
Item No. | Description | Classification | MM=Color temp. | Luminous flux | |
□ | TLA9-2FT20-MMK-E |
2' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 20W, 80CRI, 20-65K Emergency 2W3HRS LiFePO4 |
D80 |
2700K 4000K 5000K 5700K 6500K |
2200 lm 2340 lm 2360 lm 2340 lm 2300 lm |
□ | TLA9-4FT40-MMK-E |
4' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 40W, 80CRI, 20-65K Emergency 2W3HRS LiFePO4 |
D80 |
2700K 4000K 5000K 5700K 6500K |
4480 lm 4800 lm 4840 lm 4800 lm 4760 lm |
□ | TLA9-5FT60-MMK-E |
5' LED Weatherproof Batten light, Voltage200-240V 50/60Hz, Power 60W, 80CRI, 20-65K Emergency 2W3HRS LiFePO4 |
D100 |
2700K 4000K 5000K 5700K 6500K |
6780 lm 7200 lm 7320 lm 7260 lm 7200 lm |
Surface mounted and suspend mounted available
