IP65 Emergency Bulkhead

At FANXSTAR, we are proud to introduce our IP65 Emergency Bulkhead, a self-contained LED emergency IP65 Bulkhead. As a leading manufacturer and supplier of Emergency bulkhead in China, we place utmost emphasis on forging positive working relationships with our partners and customers, continuously fostering improvement. Our primary objective is to offer a comprehensive range of effortlessly installable emergency bulkhead solutions tailored to diverse applications and situations. We firmly believe that a win-win business model is essential for ensuring mutual success and satisfaction among all stakeholders involved.

Send Inquiry

Product Description

FANXSTAR Self-contained LED Emergency IP65 Bulkhead BH1

Fanxstar BH1 emergency bulkhead IP65 Emergency Bulkhead is not just a fixture; it's a statement piece. Boasting a weatherproof and exquisitely sleek design, this bulkhead offers both functionality and elegance. With its extended lifespan, maintenance costs are significantly reduced, making it the perfect fit for high-traffic environments found in retail stores, shopping centers, art galleries, and council buildings. To further cater to diverse needs, it comes with five distinct installation plans. The BH1 LED emergency bulkhead features Manual Testing and a Li-ION battery, ensuring a robust emergency power output of 1W3 HRS. Our commitment to durability and customer satisfaction is reflected in the comprehensive five-year warranty that backs this exceptional product.

FANXSTAR Emergency LED Light BH1 Specification

Item	Part Number	BH1/MT
Item	Description	LED Waterproof IP65 Wall / Ceiling Mount 24m Exit Light
Working	Mode of Operation	Maintained / Non-Maintained
Input	Voltage&Frequency	220-240Vac, 30mA\|50/60Hz
Input	Installation	Terminal Blocks, 2x1.0mm² cable entry
Output	Light Source	High performance LEDs, 100,000 hours
	Luminous Flux	204lm ± 10%
	Power Consumption	4.5W(Standby)
	Emergency Duration	> 180minutes
Controls	Charger	16hrs intelligent 3-stage charger with battery management system
	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Testing Facility	Manual test switch
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	UL94V0 Flame-retardant polycarbonate
	Mounting	Surface mounted - wall or ceiling
	Colour	Two colors for optional: white and black
	Dimensions L x W x H	300mm x 110mm x 70mm
	IP Rating	IP65
	Weight	1.25kg
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	0° to 50°C
Environment	Relative Humidity	0 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
Compliance	AS/NZS 2293 Classification	C0 D6.3, C90 D3.2
Accessories	Replacement Battery	P/N: BAT-ONE: Li-ion 3.7V 2200mA
