IP65 LED Emergency Bulkhead

Fanxstar is a leading IP65 LED Emergency Bulkhead manufacturer and supplier based in China. Our flagship product, the Bulkhead BH2, boasts an IP65 waterproof rating and delivers high output during emergencies. For the past 7 years, we've consistently provided top-quality LED emergency exit sign products at competitive prices to our clients. Our business footprint spans over 90 countries and regions worldwide, reflecting our commitment to global outreach.
We prioritize collaboration with our partners and customers, fostering a positive working relationship aimed at constant improvement. Our goal is to innovate and create more adaptable, user-centric emergency bulkhead solutions. We firmly believe in cultivating a win-win business model, ensuring mutual success for all involved stakeholders.

Send Inquiry

Product Description

FANXSTAR Self-contained LED Emergency IP65 Bulkhead BH2

FANXSTAR introduces the Bulkhead BH2 IP65 LED Emergency Bulkhead, an elegant and weatherproof emergency LED bulkhead. Engineered with impact-resistant protection, it offers unmatched flexibility for both interior and exterior use across various locations. With five versatile installation options, it caters to diverse application needs seamlessly. LED emergency bulkhead includes Manual Testing, Self Testing, and DALI-2 compatibility, providing flexibility in emergency lighting management and control.This emergency bulkhead with an integrated high capacity LiFePO4 battery and providing IP65 ratings for durability and protection. It offers a 3-hour emergency time to supply power to the fittings during power outages.Our emergency waterproof LED luminaires are backed by a solid five-year warranty, ensuring reliability and peace of mind our customers.

FANXSTAR Emergency LED Light BH2 Specification

Item	Part Number	BH2/MT
Item	Description	LED Waterproof IP65 Wall / Ceiling Mount 24m Exit Light
Working	Mode of Operation	Maintained / Non-Maintained
Input	Voltage&Frequency	220-240Vac, 30mA\|50/60Hz
Input	Installation	Terminal Blocks, 2x1.0mm² cable entry
Output	Light Source	High performance LEDs, 100,000 hours
	Luminous Flux	220lm ± 10%
	Power Consumption	4.5W(Standby)
	Emergency Duration	> 180minutes
Controls	Charger	16hrs intelligent 3-stage charger with battery management system
	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Testing Facility	Manual test switch
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	UL94V0 Flame-retardant polycarbonate
	Mounting	Surface mounted - wall or ceiling
	Colour	Two colors for optional: white and black
	Dimensions L x W x H	300mm x 110mm x 70mm
	IP Rating	IP65
	Weight	1.25kg
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	0° to 50°C
Environment	Relative Humidity	0 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
Compliance	AS/NZS 2293 Classification	C0 D6.3, C90 D3.2
Accessories	Replacement Battery	P/N: BAT-ONE:LiFePO4 3.2V 1600mA
