Emergency LED Highbay Light
  • Emergency LED Highbay LightEmergency LED Highbay Light
  • Emergency LED Highbay LightEmergency LED Highbay Light
  • Emergency LED Highbay LightEmergency LED Highbay Light
  • Emergency LED Highbay LightEmergency LED Highbay Light
  • Emergency LED Highbay LightEmergency LED Highbay Light

Emergency LED Highbay Light

Fanxstar proudly stands at the forefront of the Emergency LED highbay lights industry as a distinguished manufacturer and supplier in China, highlighting our premier product, the H200—an embodiment of our commitment, featuring an exceptional IP65 DALI-2 Emergency LED High bay with Sensor, accompanied by an IP65 waterproof High output emergency LED high bay lighting solution.
Over the past 7 years, our unwavering dedication has been to deliver top-tier LED highbay luminaires at competitive prices to our esteemed clients. With a global presence spanning 90 countries and regions through our robust export network, we've firmly entrenched ourselves worldwide. Our ongoing dedication revolves around proactive collaboration with partners and customers, aimed at consistently refining and innovating more adaptable, customized, and user-friendly DALI-2 Emergency LED highbay fixtures. This enduring commitment remains pivotal in our mutually beneficial business model, placing growth and stakeholder satisfaction as our primary objectives.

Send Inquiry

Product Description

FANXSTAR DIP switchable to 200W/150W/100W Microwave radar induction/ emergency interface/integrated design DALI-2 LED Highbay Light H200

LED Highbay Light with battery backup H200 is a remarkable product from Fanxstar and plays a key role in their product portfolio. It is an emergency driver specifically designed for Emergency LED high bay luminaires and LED flood lights, making it suitable for smart industrial applications. This emergency driver provides 5W of emergency power and is designed to support a wide range of LED loads, with an output voltage range of 20V to 300V DC. This flexibility allows it to cover almost every fitting in warehouse, schools, and facade lighting applications. The DALI-2 Emergency LED Highbay Lights H200 features a die-cast aluminum housing with an integrated high capacity LiFePO4 battery, providing IP65 and IK08 ratings for durability and protection. The Emergency LED High bay Light fitting offers a 3-hour emergency time to supply power to the fittings during power outages. The DALI 2.0 emergency LED High bay Lights H200 offers two optional installation accessories: horizontal and vertical brackets, allowing for versatile installation options. It also includes additional holes designed to work with a WIFI sensor, enabling the creation of a smart industrial high bay lighting system with various functions such as lux monitoring control, panel monitoring, and energy consumption analysis. Importantly, the LED High-bay Light H200 has been awarded as the world's first high-power emergency driver in DALI 2.0, according to DALI Alliance verification in August 2022. This certification confirms its compatibility and compliance with DALI 2.0 standards.


FANXSTAR Emergency LED Highbay Light H200 Specification

Item Part Number H200/MT H200/ST H200/DALI
Description Integrated Microwave Sensor & Emergency Interface Highbay Light
Working Mode of Operation Multimode - Maintained / Non-Maintained
Voltage&Frequency 220-240Vac, 50/60Hz
Input Installation Suspending/wall mounted to meet different customer needs
Light Source High lumens SMD2835
Output Color Temperature MM=27-65 stands for 2700-6500K
Luminous Flux 150LM/W(R80) or 190LM/W(R70) ±10%
Power Consumption 200W,DIP switchable to150W/100W
Beam Angle 90°, one Angle can cover more than 90% of the marke
Controls Protection Overcharge, low voltage disconnect, overcurrent, short circuit
Multimode 0-10V Dimming, Sensor and Emergency for optional
Emergency Charger 16hr intelligent 3-stage charger with battery management system
Emergency Power 5W (Non-Maintained)
Duration Time > 180 minutes
Testing Facility Manual test, Self test, DALI2.0
Indicators Battery charger green LED, Function failure through red LED.
Physical Construction Diffuser - high transmission opal polycarbonate, chassis - Aluminum
Mounting Suspending/wall mounted
Colour Black
Dimensions L x W x H φ300mm x 87mm|Ekits-503: 380mm x 123mm x 57 mm
IP Rating IP65
Weight 2.3kg| Ekits-503: 1.7kg
Warranty 5 years on product, 3 years on battery
Environment Operating Temperature -40° to 50°C
Relative Humidity -10 to 95%
Compliance Standards CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
AS/NZS 2293 Classification C0 D125, C90 D80
Accessories Microwave Dimming Sensor P/N: H200-S: MC094-S03
Replacement Battery P/N: BAT-One: LiFePO4 6.4V 4000mA

Note: Product specifications subject to change without prior notice due to ongoing product improvement policy and changes to industry standard


FANXSTAR emergency LED Highbay Lights H200 Feature And Application

HBL 200W Range (DIP switchable to150W/100W)

High Lighting efficiency: 150LM/W(R80) or 190LM/W(R70)

Suspending/wall mounted to meet different customer needs

Economical 5W3HRS (MT/ST/DALI) Emergency Kits with LiFePO4

Microwave radar induction/emergency interface/integrated design


FANXSTAR DALI emergency LED Highbay Light H200 Details

HBL 200W Range (DIP switchable to150W/100W) of DALI-2 LED Highbay Lighting

Emergency LED Highbay Light Fixture With HBL 200W Range (DIP switchable to150W/100W)

Economical 5W3HRS (MT/ST/DALI) Emergency Kits with LiFePO4 of Emergency LED Highbay Light

With Suspending/wall mounted sensor LED Highbay Luminaire to meet the needs of different customer.


Emergency Highbay Lighting fitting H200 Dimensions


Emergency Highbay fixtures H200 Packing
