Non-Maintained 3W Surface Mounted LED Spitfire Emergency Light

Introducing the latest addition to the Fanxstar Xlite Series - a versatile recess or surface-mounted non-maintained emergency LED light that meets the stringent Australian AS/NZS 2293 emergency standard, specifically Class D63. Powered by the advanced LUXEON 5050 from Lumileds, this LED emergency luminaire ensures a remarkable 70CRI rating, delivering an impressive lumen output of up to 360lm. Its robust hot-color targeting system guarantees LED reliability, even in challenging conditions of up to 85°C.
Dubbed the LED Spitfire, this meticulously crafted surface ceiling -mountable LED emergency light seamlessly integrates a resilient and luminous LED lamp with the innovative Kino.mo™ lens. This powerful integration promises dependable and distinct illumination, effectively alleviating panic and establishing a secure egress path during emergencies.
esigned for effortless surface mounting, this LED emergency lighting luminaire comes equipped with a high-quality LiFe PO4 battery, ensuring a minimum duration of 180 minutes. Leveraging its extended lifespan, this luminaire minimizes maintenance costs while catering to the high-traffic needs of public buildings, including retail stores, shopping centers, galleries, and council buildings. Backed by a comprehensive five-year warranty, this LED Emergency Luminaire fitting epitomizes our unwavering commitment to durability and customer satisfaction.

Send Inquiry

Product Description

FANXSTAR D63 LED Surface Mounted All-in-One

NON-MAINTAINED EMERGENCY LED LIGHT Xlite X3

Introducing the FANXSTAR Xlite X3 from the No.128 range—an all-inclusive LED emergency surface downlight. This innovative solution integrates an integrated driver and battery, providing a hassle-free package for emergency lighting needs.

Engineered with an enhanced optical system, the Xlite X3 emergency LED light complies with both European EN1838 and AS/NZS2293 standards, meeting stringent D63 emergency requirements. Featuring the LUXEON 5050, a high-power, multi-die package delivering exceptional luminance within a single, cost-effective optic, the Spitfire emergency LED light Xlite X3 is ideally suited for corridors, pathways, hallways, and various other settings.

Available in two stylish color options—white (RAL 9016) and black (RAL 9005)—the Xlite X3 stands out with its large terminals (PA14/PA16), catering to terminal connection requirements of φ2.5-4.0㎡ in business and industrial settings. The LiFePO4 3.2V 3.2Ah battery pack ensures over 3 hours of emergency load, offering reliable illumination during power outages. Additionally, for advanced functionality, a special custom version with DALI2.0 emergency function is available upon request.

Illuminate your spaces with confidence, simplicity, and cost-effectiveness—choose the Xlite X3 emergency LED luminaire for your emergency lighting requirements.

FANXSTAR Emergency LED Lights X3 Specification

Item	Part Number	Xlite X3/MT	Xlite X3/ST	Xlite X3/DALI
	Description	D63 LED Surface Mounted All-in-One Non-Maintained Emergency Light
Working	Mode of Operation	Non-Maintained
Input	Voltage&Frequency	220-240Vac, 30mA\|50/60Hz
	Installation	Large Terminal Blocks - PA14/PA16
Output	Light Source	Lumileds LUXEON 5050 1x5W
	Luminous Flux	360lm±10%
	Power Consumption	2.5W(Standby)
	Emergency Duration	> 120 minutes
Controls	Charger	16hr intelligent 3-stage charger with battery management system
Emergency	Protection	Overcharge, low voltage disconnect, overcurrent, short circuit
	Testing Facility	Manual test	Self test	DALI2.0
	Indicators	Battery charger green LED, Function failure through red LED.
Physical	Construction	UL94V0 Flame-retardant polycarbonate
	Mounting	Surface mounted - ceiling
	Colour	Two colors for optional: white and black
	Dimensions L x W x H	200mm x 200mm x 52mm
	IP Rating	IP20
	Weight	1.02kg
	Warranty	5 years on product, 3 years on battery
Environment	Operating Temperature	0° to 50°C
	Relative Humidity	0 to 95%
Compliance	Standards	CE/UKCA/RCM, EN1838, IEC60598.1, AS/NZS 2293
	AS/NZS 2293 Classification	C0 D63, C90 D63
Accessories	Replacement Battery	P/N: BAT-ONE: LiFePO4 3.2V 3200mA
